Mode4-EVSE-DC-Charger-Pile
FP-G4A-B7 series
FP-G4A-B7 series
Waterproof and dustproof
High temperature failure protection
Bluetooth reservation charging
Authoritative certification
Suitable for 99.9% of vehicles
Lifetime technical service
Supports wall hanging or column installation
FP-G4A-B7 series
FP-G4A-B7 series
Product advantage
Passed CQC safety certification
Multiple protection
High temperature power failure
Suitable for 99.9% of models on the market
Waterproof and dustproof
Support Bluetooth reservation charging
Support 4G scanning code charges
Product advantage
Passed CQC safety certification
Multiple protection
High temperature power failure
Suitable for 99.9% of models on the market
Waterproof and dustproof
Support Bluetooth reservation charging
Support 4G scanning code charges
Equipment parameter

S/N

序號

Function Items

功能性項目

Parameter

參數

1

Model

型號

FP-G4A-B7

2

Input Voltage Range

輸入電壓范圍

AC 85V~265V，Typical AC 220V

3

Input Frequency Range

輸入頻率范圍

47Hz~63Hz，Typical 50Hz

4

Output Power Range

輸出功率范圍

0~6600W

5

Output Voltage Range

輸出電壓范圍

DC 200V~580V

6

Constant Power Voltage Range

恒定功率電壓范圍

DC 330V~580V

7

Output Current Range

輸出電流范圍

0~20A

8

Power Factor

功率因數

≥0.99

9

Peak Efficiency

峰值效率

≥95%

10

Reference Standards

參考標準

GB/T 20234.1-2015，GB/T 20234.3-2015，GB/T 27930-2015，GB/T 18487.1-2015，NB/T 3300-2018

11

Starting Mode

啟動方式

One-Button Start And Stop；BT Appointment Start

12

Protection Function

保護功能

Over Voltage、Under Voltage、Over Load、Short Circuit、Over Current 、Over Temperature、Leakage、Lighting

13

Noise

噪音

≤60dB

14

Cooling Mode

冷卻方式

Forced Air Cooling

15

Class Of Protection

防護等級

IP54

16

Operation Temperature

工作溫度

-30℃~+50℃（Intelligent Over Temperature Protection）

17

Relative Humidity

相對濕度

5%~95%

18

Altitude

海拔高度

≤2000m

19

Atmospheric Pressure

大氣壓力

70KPa~106Kpa

20

Applicable Environment

適用環境

Indoor or Outdoor

21

Product Size（mm）

產品尺寸

480X320X120

22

Package Size (mm)

包裝尺寸

610X380X290

23

Equipment Weight

設備重量

≈13.3kg

24

Outer Packaging Gross Weight

外箱毛重

≈14.7kg

25

Line Length

槍線長度

4m

26

Input Line Length

進線長度

1m
